Product picture |
PartNumber |
Features
请选择
请选择
150mA Ultra-Low IQ Enable Input
1A Low Drop ADJ Output
1A Low Drop Fixed Output
1A Low Drop Low Noise Fixed Output
1A, Low Noise, High PSRR, Low Dropout LDO with PG
1A, Low Noise, High PSRR, Low Dropout LDO
250mA Ultra-Low IQ Enable Input
300mA Low IQ High PSRR Low Noise
300mA Low IQ Ultra High PSRR Ultra Low Noise
300mA Low IQ Very High PSRR Very Low Noise
300mA Ultra-Low IQ Enable Input
300mA, Ultra-Low IQ, Enable Input
300mA，Capacitor-Free，Low Drop
400mA Low IQ Ultra High PSRR Ultra Low Noise
400mA Low Voltage Output
500mA Low Drop ADJ Output
500mA Low Drop Enable Input
500mA Low Drop Fixed Output
|
VIN(V)
请选择
请选择
1.1~5.0
1.2~5.0
1.2~5.5
1.4~5.5
1.6~5.5
1.7~5.5
1.8~5.5
1.9~5.5
1.9~6.0
2.0~6.0
2.2~5.5
|
VOUT(V)
请选择
请选择
0.6/0.85/0.9/1.1/1.8
0.75/0.8/1.05/1.1 /1.2/1.8
0.8/1.0/1.1/1.2/1.5/1.8/2.4/2.5/2.8/2.85/2.9/3.0/3.3
0.8/1.2/1.8/2.5/2.8/3.0/3.3
0.85/1.0/1.1/1.2
1.05/1.1/1.2/1.5/1.8/2.2/2.5/2.8/2.9/3.0/3.3
1.05/1.1/1.2/1.8/2.2/2.8/2.85/3.0/3.1/3.3
1.05/1.2/1.8/2.8/3.0/3.3/3.6/5.0
1.1/1.2/1.5/1.8/2.4/2.5/2.8/2.85/2.9/3.0/3.3
1.1/1.2/1.75/1.8/2.5/2.8/3.0/3/3
1.1/1.2/1.8/2.2/2.8/3.0/3.1/3.3
1.2/1.35/1.5/1.7/1.8/2.5/2.8/3.0/3.3
1.2/1.5/1.6/1.7/1.8/2.2/2.5/2.8/2.85/2.9/2.95/3.0/3.1/3.3
1.2/1.5/1.8/2.5/2.8/3.0/3.3
1.2/1.5/1.8/2.5/2.8/3.0/3.3/3.6V
1.2/1.8/2.8/3.3
1.2/1.8/3.0
1.2，1.8，2.8，3.3
1.8/2.2/2.8/3.0/3.3
1.8/2.8/3.0/3.3
1.8/3.0/3/3
3.0/3/3
ADJ/0.55~4.3
ADJ/0.75~4.3
ADJ/0.8~5.0
ADJ/1.0~3.6
ADJ/1.0~5.0
|
IOUT(mA)
请选择
请选择
150
250
300
400
500
1000
|
Dropout Voltage @IOUT (mV)
请选择
请选择
100@3.3V
115@3.3V
135@2.8V
135@3.3V
140@3.3V
160
160@2.8V
170@2.8V
180@1.8V
180@2.8V
190@2.8V
230@2.8V
240@2.8V
240@3.3V
250@2.8V
260@2.8V
260@3.3V
265@2.8V
280@1.8V
280@3.3V
280@3.6V
330@2.8V
350@1.8V
350@2.8V
370@3.3V
380@3.3V
430@1.1V
520@0.8V
|
IQ (μA)
请选择
请选择
0.2
0.6
0.8
15
20
25
35
42
45
48
50
55
60
110
145
|
PSRR@1kHz (dB)
请选择
请选择
55
60
62
63
70
75
78
80
85
90
100
|
Noise (μVRMS)
请选择
请选择
10
15×VOUT
20
20×VOUT
35
40×VOUT
9
40
45
50×VOUT
60
70
75
80
240
|
Package
请选择
请选择
DFN4(0.8X0.8)
DFN4(1.0X1.0)
DFN4(1.0X1.0)/ SOT23-5
DFN4(1.0X1.0)/ SOT23-3/ SOT23-5/ SC70-5/SOT89-3
DFN4(1.0X1.0)/ SOT23-5
DFN4(1.0X1.0)/ SOT23-5/SC70-5
DFN4(1.0X1.0)/ SOT23-5/SOT23-3
DFN4(1.0X1.0)/ WLCSP4(0.4 Pitch)
DFN4(1.0X1.0)/DFN4(0.8X0.8)/SOT23-5
DFN4(1.0X1.0)/DFN6(1.2X1.2)/SOT23-5
DFN4(1.0X1.0)/SOT23-5
DFN4(1.0X1.0)/SOT23-5/SC70-5
DFN4(1.0X1.0)/SOT23-5/SOT23-3
DFN4(1.0X1.0)/WLCSP4(0.4 Pitch)
DFN4(1.2X1.2)
DFN6(1.5X1.0)/DFN6(2.0X2.0)/DFN8(1.2X1.6)
DFN6(2.0X2.0)
DFN8(1.2X1.6)/ SOT23-5/ DFN6(2.0X2.0)/ DFN6(2.0X2.0)
DFN8(3.0X3.0)
SOT23-5
SOT23-5/ SOT89-5/DFN4(1.2X1.2)/ DFN6(2.0X2.0)
SOT23-5/DFN6(2.0X2.0)
|
|---|---|---|---|---|---|---|---|---|---|---|
|
ET538XXYB | 400mA Low IQ Ultra High PSRR Ultra Low Noise | 2.2~5.5 | 1.8/2.2/2.8/3.0/3.3 | 400 | 180@2.8V | 20 | 100 | 9 | DFN4(1.0X1.0)/ WLCSP4(0.4 Pitch) |
|
ET542XXY1B | 400mA Low Voltage Output | 1.1~5.0 | 0.85/1.0/1.1/1.2 | 400 | 280@1.8V | 55 | 80 | 40×VOUT | DFN4(1.0X1.0) |
|
ET559XX | 500mA Low Drop Fixed Output | 1.9~5.5 | 1.05/1.2/1.8/2.8/3.0/3.3/3.6/5.0 | 500 | 280@3.6V | 60 | 85 | 45 | DFN4(1.0X1.0)/SOT23-5 |
|
ET539XXYB | 300mA Low IQ Ultra High PSRR Ultra Low Noise | 1.7~5.5 | 1.1/1.2/1.5/1.8/2.4/2.5/2.8/2.85/2.9/3.0/3.3 | 300 | 380@3.3V | 35 | 75 | 45 | DFN4(1.0X1.0) |
|
ET523XX | 300mA Low IQ High PSRR Low Noise | 1.7~5.5 | 1.2/1.5/1.8/2.5/2.8/3.0/3.3 | 300 | 265@2.8V | 50 | 75 | 70 | DFN4(1.0X1.0)/ SOT23-5 |
|
ETQ5A7ADJY1 | 1A, Low Noise, High PSRR, Low Dropout LDO with PG | 2.2~5.5 | ADJ/0.8~5.0 | 1000 | 160 | 145 | 63 | 15×VOUT | DFN8(3.0X3.0) |
|
ETQ5A7ADJY | 1A, Low Noise, High PSRR, Low Dropout LDO | 2.2~5.5 | ADJ/0.8~5.0 | 1000 | 160 | 145 | 63 | 15×VOUT | DFN8(3.0X3.0) |
|
ET5A0ADJAY2B | 1A Low Drop ADJ Output | 1.8~5.5 | ADJ/0.55~4.3 | 1000 | 115@3.3V | 110 | 70 | 50×VOUT | DFN6(2.0X2.0) |
|
ET5A0ADJ | 1A Low Drop ADJ Output | 1.8~5.5 | ADJ/0.75~4.3 | 1000 | 135@3.3V | 110 | 70 | 50×VOUT | DFN6(1.5X1.0)/DFN6(2.0X2.0)/DFN8(1.2X1.6) |
|
ET537XXY1B | 400mA Low IQ Ultra High PSRR Ultra Low Noise | 1.6~5.5 | 1.1/1.2/1.8/2.2/2.8/3.0/3.1/3.3 | 400 | 140@3.3V | 45 | 70 | 20 | DFN4(0.8X0.8) |
|
ET537XXYB | 400mA Low IQ Ultra High PSRR Ultra Low Noise | 1.6~5.5 | 1.1/1.2/1.8/2.2/2.8/3.0/3.1/3.3 | 400 | 240@3.3V | 48 | 70 | 35 | DFN4(1.0X1.0) |
|
ET5A8XX | 1A Low Drop Low Noise Fixed Output | 1.9~5.5 | 1.8/3.0/3/3 | 1000 | 260@3.3V | 25 | 80 | 10 | SOT23-5/DFN6(2.0X2.0) |
|
ET5A0XX | 1A Low Drop ADJ Output | 1.8~5.5 | 1.1/1.2/1.75/1.8/2.5/2.8/3.0/3/3 | 1000 | 100@3.3V | 110 | 70 | 50×VOUT | DFN8(1.2X1.6)/ SOT23-5/ DFN6(2.0X2.0)/ DFN6(2.0X2.0) |
|
ET5A0ADJY2B | 1A Low Drop ADJ Output | 1.8~5.5 | ADJ/0.75~4.3 | 1000 | 135@3.3V | 110 | 70 | 50×VOUT | DFN6(2.0X2.0) |
|
ET639XX | 300mA, Ultra-Low IQ, Enable Input | 2.0~6.0 | 1.2，1.8，2.8，3.3 | 300 | 260@2.8V | 0.6 | 75 | 50×VOUT | DFN4(1.0X1.0)/SOT23-5/SOT23-3 |
|
ET5A8XXYB | 1A Low Drop Fixed Output | 1.9~5.5 | 3.0/3/3 | 1000 | 280@3.3V | 25 | 90 | 10 | SOT23-5/DFN6(2.0X2.0) |
|
ET538XXZB | 400mA Low IQ Ultra High PSRR Ultra Low Noise | 2.2~5.5 | 1.8/2.2/2.8/3.0/3.3 | 400 | 180@2.8V | 20 | 100 | 9 | DFN4(1.0X1.0)/WLCSP4(0.4 Pitch) |
|
ET635XX | 300mA, Ultra-Low IQ, Enable Input | 1.2~5.5 | 1.2/1.8/2.8/3.3 | 300 | 370@3.3V | 0.2 | 60 | 70 | DFN4(1.0X1.0)/ SOT23-5 |
|
ET634XX | 250mA Ultra-Low IQ Enable Input | 1.8~5.5 | 1.2/1.5/1.8/2.5/2.8/3.0/3.3/3.6V | 250 | 330@2.8V | 0.8 | 62 | 80 | DFN4(1.0X1.0)/DFN4(0.8X0.8)/SOT23-5 |
|
ET552XXY1B | 500mA Low Drop Enable Input | 1.2~5.0 | 0.6/0.85/0.9/1.1/1.8 | 500 | 430@1.1V | 55 | 80 | 40 | DFN4(1.0X1.0) |
|
ET533XX | 300mA Low IQ High PSRR Low Noise | 2.0~6.0 | 1.2/1.35/1.5/1.7/1.8/2.5/2.8/3.0/3.3 | 300 | 240@2.8V | 42 | 75 | 75 | DFN4(1.0X1.0)/SOT23-5/SC70-5 |
|
ET540XX | 500mA Low Drop Enable Input | 1.2~5.0 | 0.75/0.8/1.05/1.1 /1.2/1.8 | 500 | 520@0.8V | 50 | 70 | 40 | DFN4(1.0X1.0)/DFN6(1.2X1.2)/SOT23-5 |
|
ET633XX | 300mA Ultra-Low IQ Enable Input | 2.2~5.5 | 1.8/2.8/3.0/3.3 | 300 | 350@2.8V | 0.6 | 55 | 70 | DFN4(1.0X1.0)/ SOT23-5 |
|
ET631XX | 150mA Ultra-Low IQ Enable Input | 2.2~5.5 | 1.2/1.5/1.8/2.5/2.8/3.0/3.3 | 150 | 170@2.8V | 0.6 | 55 | 70 | DFN4(1.0X1.0)/ SOT23-5/SOT23-3 |
|
ET536XX | 300mA Low IQ Very High PSRR Very Low Noise | 1.6~5.5 | 1.05/1.1/1.2/1.8/2.2/2.8/2.85/3.0/3.1/3.3 | 300 | 160@2.8V | 45 | 78 | 40 | DFN4(1.0X1.0) |
|
ET531XX | 300mA Low IQ Ultra High PSRR Ultra Low Noise | 1.9~5.5 | 1.2/1.5/1.6/1.7/1.8/2.2/2.5/2.8/2.85/2.9/2.95/3.0/3.1/3.3 | 300 | 135@2.8V | 15 | 80 | 10 | DFN4(1.0X1.0)/ SOT23-5 |
|
ETQ553ADJYB | 500mA Low Drop ADJ Output | 1.9~5.5 | ADJ/1.0~3.6 | 500 | 350@1.8V | 50 | 80 | 20×VOUT | DFN4(1.2X1.2) |
|
ET553XX | 500mA Low Drop Fixed Output | 1.9~5.5 | 1.8/2.8/3.0/3.3 | 500 | 350@1.8V | 50 | 80 | 20×VOUT | DFN4(1.0X1.0)/ SOT23-3/ SOT23-5/ SC70-5/SOT89-3 |
|
ET553ADJ | 500mA Low Drop ADJ Output | 1.9~5.5 | ADJ/1.0~5.0 | 500 | 350@1.8V | 50 | 80 | 20×VOUT | SOT23-5/ SOT89-5/DFN4(1.2X1.2)/ DFN6(2.0X2.0) |
|
ET552XX | 500mA Low Drop Enable Input | 1.2~5.0 | 0.6/0.85/0.9/1.1/1.8 | 500 | 430@1.1V | 55 | 80 | 40 | DFN4(1.0X1.0) |
|
ET519XX | 300mA，Capacitor-Free，Low Drop | 1.4~5.5 | 1.2/1.8/3.0 | 300 | 180@1.8V | 60 | 60 | 240 | SOT23-5 |
|
ET518XX | 300mA Low IQ High PSRR Low Noise | 1.7~5.5 | 0.8/1.2/1.8/2.5/2.8/3.0/3.3 | 300 | 230@2.8V | 45 | 70 | 35 | DFN4(1.0X1.0) |
|
ET516XX | 300mA Low IQ High PSRR Low Noise | 1.9~5.5 | 0.8/1.0/1.1/1.2/1.5/1.8/2.4/2.5/2.8/2.85/2.9/3.0/3.3 | 300 | 190@2.8V | 45 | 75 | 60 | DFN4(1.0X1.0)/ SOT23-5/SC70-5 |
|
ET515XX | 300mA Low IQ High PSRR Low Noise | 1.9~6.0 | 1.05/1.1/1.2/1.5/1.8/2.2/2.5/2.8/2.9/3.0/3.3 | 300 | 250@2.8V | 42 | 75 | 70 | DFN4(1.0X1.0) |
